2.8-12MM outdoor security dome cctv outdoor wireless cloud ip camera with two audio

FOB Reference Price:Get Latest Price
$65.50 - $70.00 / Sets | 10 Set/Sets (Min. Order)
Type:
IP Camera
Style:
Dome Camera
Resolution:
1280 X 720 1920 x 1080
Lead Time:
Quantity(Sets) 1 - 100 >100
Est. Time(days) 3 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
SIEPEM
Model Number:
SMD6830F-WR
Sensor:
CMOS, 1/2.7" Progressive Scan 2MP CMOS
Special Features:
Waterproof / Weatherproof
OS:
Embedded Linux OS
Lens Type:
2.8-12MM
Processor:
Hi3516C
First Stream:
1080P(1920*1080),720P(1280*720)
Rotation Angle:
Pan:355°, Tilt: 90°
Wireless Standard:
WIFI, 802.11b/g/n
Compression format:
G.711(G.711 Default)
Night Visibility:
3 array Led lights,night vision is up to 50m
Warranty:
Limited 2-Year Warrant
Supply Ability
Supply Ability:
500 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Color box
MEAS:203*203*134mm (LxWxH)
N.W.: 886.5g G.W.: 1.5kg(Note:Actual Weight Final)
Port
shenzhen
Lead Time :
Quantity(Sets) 1 - 100 >100
Est. Time(days) 3 To be negotiated

2.8-12MM outdoor security dome cctv outdoor wireless cloud ip camera with two audio

Product Description

 Specification

ModelSMD6830F-WRAPP:WANSCAM
SsystemSystem Security

Supports one-level account, password, user authority

management.

OSEmbedded Linux OS
ProcessorHi3516C
P2P (Free)No need to preset camera, Offer free  P2P(xxxx-xxxxxx-xxxxx), Plug&play, Support  QR code scanning to view
Onvif ProtocolSupport ONVIF Protocol
Multi-device function

Support 12 language remote surveillance, record, alarm,

wifi setting etc.

PC clientSupport remote multi-devices monitor, record, alarm etc;Support windows and mac os
Cell Phone ViewSelf R&D APP, Support Iphone,Android smart Phone
TF Card RecordSupport max 128GB,
LensLens Type2.8-12MM
IR-CUTBuild-in IR CUT, no color cast,auto switch when IR on
VideoImage CompressionH.264/MJPEG
Sensor1/2.7" Progressive Scan 2MP  CMOS
Video Parameters

Brightness, Contrast,Saturation,Exposure,sharpness can

be adjusted

Image Frame Rate50Hz:25fps/60HZ:30fps (1920×1080)
First Stream1080P(1920×1080),720P(1280x720)
AudioSecond StreamVGA-(640x352),(320x176)
Compression formatG.711(G.711 Default)
Audio InBuilt in Mic
Audio OutBuilt in Speaker
Night VisionNight Visibility3 array Led lights,night vision is up to 50m
LuxIR ON 0 LUX
Pan/TiltPresetSupport 8 Preset Positions
Rotation AnglePan:355°,  Tilt: 90°
Rotation SpeedPan: Speed Range 5-50°/ S; Tilt: Speed Range 5-30°/ S;
AlarmMotion Detect

Support 4 Independent detection areas(Sensitivity

can be adjustd 1-100)

Alarm Action

Support Email Photo Alert,Snapshot and Record uploaded

to FTP

NetworkEthernet InterfaceOne 10/100Mbps RJ-45
Supported Protocol

TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,

DDNS,NTP,UPNP,RTSP etc.

Online VisitorSupport Max 6 visitors at the same time
 (First Stream:3 visitors;Second Stream:3 visitors)
IP ModeDynamic IP address, static IP address(DHCP)
Online VisitorSupport Microsoft Win XP/Win7/Win8/ win10/Mac OS.
BrowserSupport Internet Explorer 8.0-11.0, FireFox,Google Browser
One key setting  FunctionSupport one key setting function connect WIFI
Wireless StandardWIFI, 802.11b/g/n
OthersOSD

Support the OSD name, date and time info superposition

(Open/Off)

Product TypeCartoon Robot/ Indoor use
PowerDC12V/2A
Working Temperature-10~50 °C
Working Humidity95% RH
Size

Item:184*130*108mm (HxW); Packaging: 203*203*134mm

(LxWxH)

WeightN.W.: 886.5g        G.W.: 1.5kg(Note:Actual Weight Final)
AccessoriesAdaptor,Screws,Paper specifications,Ethernet Cable,CD
CertificationCE,FCC,RoHS
WarrantyLimited 2-Year Warranty

Related products
Company Information
Certifications



FAQ

1. What products do you deal with?
We mainly deal with indoor IP Camera, outdoor IP Camera, Battery IP Camera and NVR kit.



2. When will you ship my order?
Ordinary,once we get confirmation for payment,we will ship order within 2-5 days.



3. Are OEM products same features as original?
OEM products have all the same features as original, just with different model number.


4. Can I get your price list?
Yes, please tell us the products (with their code number) and order quantity, then we will
offer the price by e-mail. And our price list will keep updated every month.



5. How long time can I expected to receive the goods?
Normally we can send out the goods 3 days after the payment. Usually, air transport customers will receive the goods around 3-5 days, shipping is generally about a month to receive the goods.
